D2B Fiber Optic(MOST) adapter for Mercedes-Benz

This D2B Fiber Optic(MOST) adapter allows you to retain the factory Mercedes-Benz MOST amplifier audio system(Harman/Kardon or BOSE) when installing ANY aftermarket radios. The output from all speakers including subwoofer and premium sound quality. This makes it a nice clean easy install.
When installing this interface into your Mercedes-Benz make sure that the fiber optic signal loop is not broken.  If you have other devices which can include the original CD Changer, satellite radio, and telephone module they must stay connected so the fiber optic signal loop is consistent.
To identify if you have a fiber optics MOST factory-amplified audio system, you can check the vehicle in a number of ways. Some vehicles will have clear markings on the speaker grills indicating the presence of an upgraded audio system. You can also check with the original order notes/invoice from when the car was purchased from the factory, the upgraded sound system with an amplifier would show on the options list. If unsure, you can call your local dealer with your vehicle's chassis number and ask them to check if the vehicle was manufactured with an amplified audio system. If you are not sure, please send the VIN and a photo of the existing dashboard of your car to info@sigmacarstereo.com, we will help you to check.

Compatible vehicles:

Mercedes-Benz C-Class 2001 2002 2003 2004
Mercedes-Benz CL-Class 2000 2001 2002 2003
Mercedes-Benz CLK-Class 2001 2002 2003 2004
Mercedes-Benz E-Class 2000 2001 2002
Mercedes-Benz ML-Class 2000 2001 2002 2003 2004 2005
Mercedes-Benz S-Class 2000 2001 2002 2003
Mercedes-Benz SL-Class 2003 2004

Connection map:

1. Yellow wire-Positive of battery(usually it is the yellow wire from the aftermarket head unit main harness).
2. Red wire- ACC wire(usually it is the red wire from the aftermarket head unit main harness).
3. Black wire-GND(usually it is the black wire from the aftermarket head unit main harness).
4. RCA audio input connects to the Front left and Front right audio output of the aftermarket head unit.
5. D2B Wake up connects to the Wakeup wires from the original harness. If this wire is not connected, the original BOSE amplifier will not turn on.
6. Fiber optics plug connects to the fiber optics plug on your car.

Frequently asked questions:

Q.  Can I return this for a refund if I do not like it?
A:  NO.  We warranty the product for one year.  If there is any problems with it, we will replace it with a new one for you.

Q.  Why are there only TWO RCA inputs?
A:  It only supports stereo input from your front Left and front Right RCA audio output.

Q.   If it is only using TWO RCA audio cables how will get sound from all of my speakers?
A:  The MOST interface will convert the TWO RCA audio signals into a fiber optic signal your factory amplifier can understand.  Your Harmon Kardon amplifier will distribute sound to all of your speakers including your subwoofer.

Q.  Can I control fade and balance after this is installed?
A:  You can control only the LEFT RIGHT balance since it is only using those two RCA audio cables.  No fading from front to back.

Q.  Does this support steering wheel button controls?
A:  This does not add or remove steering wheel button control.  It only has one function and that is to convert RCA audio into a fiber optic signal the factory amplifier can understand.
