Aftermarket GPS Navigation Head Unit is specially designed to upgrade Audi A4/S4/RS4(B8) factory radio system. It has the same plug and harness as the original radio, plug, and play. This product only replaces the original LCD screen unit and retains the factory FM/CD head unit, so the original Audi car computer/CD/FM/AM/Sirius/XM will still work as before.

Android Version: 12 (genuine specs).

Vehicles Supported:
 Audi A4 B8 (Type 8K: 2008 2009 2010 2011 2012 2013 2014 2015 2016)
 Audi S4 B8 (Type 8K: 2009 2010 2011 2012 2013 2014 2015 2016)
 Audi RS4 B8 (2012 2013 2014 2015)

Before placing an order, you need to know the following items about your car:
1. What is the current radio system on my car?

AUDI MMI SYSTEM

Audi Radio system Display Software version Fitness
Chorus with MMI 2G Low/Basic 3-inch monochrome display / NOT FIT
MMI 2G High navigation system 6.5-inch monochrome display  / NOT FIT
Concert/Symphony basic radio(no navigation) 6.5-inch TFT color display / FIT
MMI 3G Low/Basic navigation system 6.5-inch TFT color display resolution 480*240 BNAV FIT
MMI 3G/3G+ navigation system 7-inch TFT color display resolution 800*480 HN+ FIT
MMI 3G High navigation system 7-inch TFT color display resolution 800*480 HNav FIT

Send a photo of the dashboard(radio system) to info@sigmacarstereo.com if you are not sure about compatibility.
2. If your car has an MMI system, then you can use the original joystick and touchscreen to operate the new Android screen.
You can still use the original joystick to operate the original Audi screen. The touchscreen does not operate the original Audi screen.
3. Please press the MEDIA button on the radio panel and check the audio source options.
If your car has the AUX(External audio input), you don't need the AMI-AUX cord.
If your car has the AMI, then you need the Audi AMI-AUX adapter cord. Please add it from the add-ons box when placing an order. Otherwise, there will be no audio after installing our product.
To find the Audi MMI version check (2G 3G 3G+ RMC high low basic)
click here.

Factory radio system:

Audi A4/S4/RS4(B8) 2008-2016 radio upgrade

Installation Photo:

Operating system Android 12
CPU 64-Bit 8-Core Cortex-A53 1.5GHz
RAM 4GB
Capacity 64GB

Display

Screen Resolution

10.25" Capacitive Touch Screen

1920*720

Network Wi-Fi
SD card One micro sd card slot
USB port Three USB ports
Camera Input One camera input(RCA port)
Microphone  External microphone
GPS receiver  Built-in GPS module and external GPS antenna



Installation video: https://youtu.be/4yijXT0Wdbw
Audi A4 high-quality system: https://www.youtube.com/watch?v=T8HNyO0N1NY

Is this product plug-and-play? Do I need to program or code my Audi? Do I need to buy an external GPS antenna? Can I still check the car info on the OEM screen?
Answer: Yes, it is totally plug-and-play, it has the same plugs and harness as the original Audi system. You do not need to program your car when installing. All necessary accessories are included in the package. You do not need to buy anything else to make it work. You can still check the original Audi car info as before.

How do I switch the new upgrade system to the original Audi interface?
Answer: Please tap the “Original” icon on the home screen to switch to the original Audi interface.

How do I switch the original Audi interface to the new upgrade system?
Answer: Please tap the screen.

Why it shows a black screen with no signal when tapping “Original” to switch back to the original Audi interface?
Answer: Please check the CAR-LVDS port. Make sure you connect the LVDS plug (removed from the OEM screen) to the new screen.

AUDI LVDS CONNECTOR

Why there is no audio from the new upgrade system?

Answer:
1. Please press the MEDIA button on the radio panel and check the audio source options. Make sure the External Audio input(AUX) is activated.

MEDIA BUTTON

Note if your car has the AMI option instead of AUX, then you need to plug the Audi AMI-AUX cord(this cord is sold separately) into the AMI port in the glove box on the passenger side. After plugging this cord, the AMI will change to AUX on the screen.

Audi AMI-AUX cord

2. Then tap the screen to access the new upgrade system. You should be able to hear sound.

Where should I mount the main metal box? The original LVDS cord is too short to mount in the glove box?

Please take apart the glove box on the passenger side and there is a hole that allows you to put the metal box hide behind the screen. Then the LVDS cord is long enough.

Audi navigation system upgrade

The T harness that plugs into the side behind the glovebox is not the right connection. photo here
Answer: Please check the attached wiring diagram here. Connect them to the CAN BUS plugs at the rear of the A/C controller panel.

I am getting TPM And and airbag error on my dash now, I assume it's due to that T harness not being plugged in.
Answer: You need to keep the original airbag/hazard button connected to the aftermarket T harness and hide it into the dash. Please check the attached picture here.

Lastly, I am not getting any audio when using CarPlay. Navigation and consoling my phone wirelessly works but no audio coming out of the speakers. It stays on the radio or CD player.
Answer: Please access the original AUDI menu and select the "AUX" audio option. Then try again.

Compatible accessories can be added via links below:

 DAB+ radio dongle (click here) (DAB not available in the U.S)
   Apple Carplay/Android auto wireless Dongle(click here) Highly recommended
  Car Front dash camera (click here)
  OBD 2 diagnostic tool (click here)
  Universal car backup camera (click here)
