Mercedes-Benz CL-Class (W215)/S-Class (W220) 1998-2005 Autoradio GPS Aftermarket Android Head Unit Navigation Car Stereo (Free Backup Camera)
This aftermarket navigation system is specially designed to replace Mercedes-Benz CL(W215)/S(W220) factory radio. It has the same harness and plug as original radio, totally plug and play when install. After install this new unit, you will get an intelligent entertainment system with Touchscreen/Navigation/FM/AM/USB/SD/WiFi/AUX-IN/Bluetooth phone call/Bluetooth music/DVD playback/DAB+(device is optional)/rear view camera(device is optional)/Apple CarPlay(device is optional)/TV(device is optional)/OBD(device is optional)/Google Play etc.
Mercedes-Benz CL-Class (W215) 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005
Mercedes-Benz S-Class (W220) 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005
Note above year range is for your reference only. Send a photo of the dashboard(radio system) to info@sigmacarstereo if you are not sure about fitness.
The audio system on Mercedes-Benz CL(W215)/S(W220) is powered by a fiber optic (D2B/MOST) amplifier in the rear of the vehicle. Head units which are run by D2B/MOST will have a pair of orange plastic fiber-optic cables on the rear and no speaker outputs. The majority of cables such as speaker wires, power wires and the radio antenna are found in the rear of the car at the original amplifier. This means that to integrate this aftermarket unit with the car you must run an extension kit to the speaker/power wires in the rear. Installations requiring the extension are more time consuming than for cars that do not require it, however it is still relatively straight forward. The extension kit is optional, please add it from the drop-box. Check more info about the Extention cord for Mercedes-Benz aftermarket head unit.
Note that ONLY 4 SPEAKERS will work after installing this kit. Please acknowledge this before place the order. Or you can also replace the factory amplifier audio system by an aftermarket amplifier system to keep all speakers work.
Factory radio FYI:
|CPU||64-Bit 8-Core Cortex-A53 1.5GHz|
|Display||7" 1024*600 Capacitive Touch Screen|
|SD card||Two micro sd card slots|
|USB port||Two USB ports|
|Amplifier||Built-in 4*45W sound amplifier|
|Audio Output||Front left, Front right, Rear left, Rear right and Subwoofer(RCA port)|
|Video Output||One video output(RCA port)|
|Audio/Video Input||Left/Right audio and video input(RCA port)|
|Camera Input||One camera input(RCA port)|
|GPS receiver||Built-in GPS module and external GPS antenna|
